Describe a body machine in detail. Mask body output by the machine, automatic spot welding machine processing, the finished product is completed in one line. The machine adopts PLC, touch screen control, main conveyor belt adopts single-phase motor transmission, accurate transmission, stable control, adjustable speed. Product features: 1. High stability, low failure rate, aesthetics without rust; 2. 2. Computer PLC programming control, high degree of automation; 1. Size: L:3500mm*W800mm*H1800mm 2. Equipment efficiency: about 600pcs/ hour 3. Non-woven fabric parameters 4. Upper layer 25 grams per square meter, width 175mm (non-woven fabric) 5. The middle layer is 25 grams per square meter, the width is 175mm (melt-sprayed non-woven cloth), the lower layer is 20 grams per square meter, the width is 190mm (non-woven cloth) 6. Nose stripe, roll, width about 3mm, thickness about 0.6-0.8mm 7. Ear band outward, 3 layers without border, size 175*95mm 8. The welding machine adopts digital signal, the power of titanium alloy welding head welder Max.2000W welding machine frequency Max.20KHz main technical parameters Model adult type child type mask size 175*95mm 145*95mm total 5kV 5kV outline size 3000*1050*1850mm total weight 400kg 400kg outline packing size 1900mm*1200mm*1450mm two packagescontact supplier or email to admin@b2bgood.com for purchase help
