Set up:1台
supply:10台
The bio clean safe cabinet is the necessary equipment in the microbiological laboratory, especially in those occasions where the operators need to take protective measures, such as medical and health care, pharmaceutical, scientific research and other bacterial culture to provide a sterile and dust-free working environment.
1. Structural characteristics:
1. The machine is made of high-quality cold-rolled steel sheet and is sprayed with static electricity. The design of the machine is beautiful and generous. The aesthetic design concept and appropriate color can make the laboratory bright at once.
2. The machine adopts mirror stainless steel operating table, which is corrosion-resistant and makes its cleaning more convenient.
2. Technical characteristics:
1. The equipment adopts the leading international air filtration technology, vertical laminar negative pressure design, and meets CLASS IITYPE A/B3 biosafety standard.
2. Unique internal cavity design, negative pressure vertical circulation direction, air curtain isolation design to prevent internal and external crossing;
3. The control system is controlled by an intelligent micro-computer. The light touch film switch adjusts the setting of parameters, and the blue display screen indicates the indicative values of parameters.
4. Equipped with a height limit alarm device, when the moving glass door exceeds the specified height limit (200mm), the user is reminded by sound and light.
5. The key components (sensing control) originate from the most advanced sensing technology in the United States in the world. They have excellent sensing performance and high sensitivity and accuracy in testing.
6. High-quality HEPA filters can achieve 99.999% or more.
Third, personalized design:
1. Humanized design takes full account of the user's needs. Using the counterweight mobile operation door, the operation door can be positioned arbitrarily at the user's desired position, making the experimental operation more convenient and simple.
2. Equipped with lighting device and ultraviolet bactericidal lamp.
Technical parameters:
Clean Class: 100@≥& micro; m (American League 209E)
Average wind speed: 0.3-0.025 m/s (adjustable)
Studio size: 1340*600*640mm
