CD40106BM96: Introduction, Features, and Applications of Hex Schmitt-Trigger Inverter

2025-07-17 11:11

Supply Voltage Range:3V to 15V
Propagation Delay (tpd):200 ns (at VDD = 10V, CL = 50pF)
Input Threshold Hysteresis:~1.2V (at VDD = 5V)
Number:2000
Price:$0.107
Packing:eel diamete

In digital electronic design, signal shaping, noise suppression, and edge control are critical to ensure system stability. The CD40106BM96 is a hex Schmitt-trigger inverter that provides six independent inverting gates with Schmitt-trigger inputs. It is widely used in industrial control, signal conditioning, and low-speed oscillator circuits. This article provides a comprehensive overview of its key features, operating principles, and application recommendations.

1. What is the CD40106BM96?

The CD40106BM96 is a CMOS logic device from Texas Instruments (TI) that integrates six independent inverting gates with built-in Schmitt trigger functionality. It is ideal for applications that require noise immunity and waveform conditioning.
