Max Output Current:±1.5mA (Typical)
Noise Margin:Approx. 0.45 × VDD
Number:2000
Price:$0.107
Packing:eel diamete
What Is CD40106BM96?
The CD40106BM96 is a hex inverting Schmitt trigger IC, meaning it contains six independent inverters with hysteresis built into each input. Unlike a regular inverter, a Schmitt trigger responds not only to logic thresholds but also provides noise rejection by introducing a differential threshold between high-to-low and low-to-high transitions.
This makes it ideal for digitizing slow or noisy analog signals into clean logic levels — a must-have in environments where electrical noise, interference, or signal bounce is common.
Key Features of CD40106BM96
-
✅ Supply voltage range: 3V to 15V
-
✅ Schmitt-trigger action with wide hysteresis for improved noise margin
-
✅ Low power consumption CMOS design
-
✅ High noise immunity: Up to 0.5VDD
-
✅ Input voltage range: 0 to VDD
-
✅ Operating temperature: -55°C to +125°C
-
✅ Available in SOIC-14 package for compact PCB mounting
-
✅ Low propagation delay for responsive switching
These features make the CD40106BM96 particularly useful in sensor signal conditioning, wave shaping, debouncing switches, oscillator circuits, and pulse generation applications.
Typical Applications
-
Signal clean-up for mechanical switches or contacts
-
Debouncing in embedded systems
-
Oscillator or square wave generation
-
Line receivers in noisy environments
-
Audio or sensor signal conditioning circuits
-
Industrial automation and automotive control units
Because of its hysteresis, the CD40106BM96 can eliminate spurious transitions caused by slow or noisy input signals — making your circuit more reliable and robust.
Why Choose CD40106BM96?
Compared to standard inverters, the CD40106BM96 offers significant benefits when handling real-world, imperfect signals. Its wide supply range and low power consumption make it suitable for both battery-operated and industrial applications. TI’s version, in particular, offers long-term availability and dependable performance, backed by rigorous quality standards.
