The machining efficiency of machine tool:
Cutting speed: according to the cutting tool material, structure, material and workpiece is in commonly50-100m/min。
Feed speed: according to the machining conditions and process conditions, in generally10-100mm/min。
Boring machining allowance largest: according to the case, determine the cutting tool structure, material and workpiece, generally no more than30mm。
the machine tool main technical specifications and parameters:
|
Technical specifications |
parameter |
|
TK2180 |
|
|
Bore diameter range |
Φ100 -Φ800mm |
|
The hole diameter range |
Φ60 -Φ120mm |
|
Processing depth range |
1-16m(Each interval1mA kind of specification) |
|
Spindle center high |
800mm 1000mm |
|
Headstock spindle aperture |
Φ100mm |
|
Spindle front cone hole |
Φ120mm,1:20 |
|
The spindle speed range, the series |
3-120r/min stepless |
|
Main motor |
55kw |
|
Feed speed range |
0.5-450 - mm/min 3 stepless |
|
Dragging plate fast moving speed |
2m/min |
|
Workpiece clamping diameter range |
400~1200mm |
|
Drill pipe box spindle aperture (optional) |
100mm |
|
Main motor |
45kw/55KW |
|
Drill pipe box end taper hole (optional) |
Φ120mm,1:20 |
|
Drill pipe box spindle speed range, series (optional) |
16-270r/min 12level |
|
The feed motor |
N=5.5 kw (Ac servo) |
|
Quick motor drag board |
N=7.5kw |
|
Cooling pump motor |
N=5.5 kw, (3group) |
|
The hydraulic pump motor |
N=1.5kw,n=1440r/min |
|
Cooling system rated pressure |
0.36MP |
|
The cooling system flow |
300、600、900L/min |
